UAP-AC-PRO Quick Start Guide. Linux, Mac OS X, or Microsoft Windows 7/8/10. (14 to 158° F) Operating Humidity 5 to 95% Noncondensing. The UAP-AC-M-PRO supports wireless adoption into your UniFi Wi-Fi network. This feature requires a currently managed UniFi AP operating with the following configuration: The UniFi AP must be running firmware 3.7.7 or newer.

Mounting Bracket
Carriage Bolts (Qty. 4)
Screws (Qty. 4)
Gigabit PoE Adapter (48V, 0.5A)*

* Included only in the single-pack of the UAP-AC-M-PRO

  • 13 mm wrench (for pole mounting)
  • Drill and 8 mm drill bit (for wall mounting)
  • Phillips screwdriver (for wall mounting)
  • Cable feed must be pointed downwards when mounted.
  • Shielded Category 5 (or above) cabling should be used for all outdoor wired Ethernet connections and should be grounded through the AC ground of the PoE.

    We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit ui.com/toughcable

  • Surge protection should be used for all outdoor installations. We recommend that you use two Ethernet Surge Protectors, model ETH-SP, one near the UAP-AC-M-PRO and the other at the entry point to the building. The ETH-SP will absorb power surges and safely discharge them into the ground.

IMPORTANT: The UAP-AC-M-PRO requires the UniFi Controller v5.4 or higher, available at: ui.com/download/unifi

System Requirements

See Full List On Dl.ubnt.com

  • Linux, Mac OS X, or Microsoft Windows 7/8/10
  • Java Runtime Environment 1.6 (1.8 or newer recommended)
  • Web Browser: Google Chrome (Other browsers may have limited functionality)
  • UniFi Controller software v5.4 or newer (available at: ui.com/download/unifi)

Wireless Adoption Requirements

The UAP-AC-M-PRO supports wireless adoption into your UniFi Wi-Fi network. This feature requires a currently managed UniFi AP operating with the following configuration:

  • The UniFi AP must be running firmware 3.7.7 or newer
  • At least one SSID enabled and operating on 5 GHz band
  • The UAP-AC-M-PRO must be within wireless range of the UniFi AP

LED

Ports

Secondary

The Secondary port is a Gigabit Ethernet port used for bridging.

Reset

The Reset button serves two functions for the UniFi AP:

  • Restart Press and release the Reset button quickly.
  • Restore to Factory Default Settings Press and hold the Reset button for more than five seconds.

Main

The Main port is a Gigabit PoE port used to connect the power and should be connected to the LAN and DHCP server. Power can be provided by one of the following:

  • Gigabit PoE Adapter (included)
  • Ubiquiti UniFi Switch with PoE
  • 802.3af/802.3at PoE+ compliant switch

Uap 158 - The Challenge Mac Os Catalina

The UAP-AC-M-PRO can be mounted on a pole or mast, or on a wall. Perform the steps for the appropriate installation.

Pole Mount

Wall Mount

Note: Secure the Mounting Bracket directly to a stud or other structurally stable surface using appropriate fasteners.

    Note: Screws shown not included.

Cached

UAP 158 - The Challenge Mac OS

OR

See “Wireless Adoption Requirements” before proceeding.

  1. Ensure the UAP-AC-M-PRO is powered on, and then launch the UniFi Controller software.
  2. Go to the Devices page, and the UAP-AC-M-PRO will show up as Pending Approval (Wireless).
  3. Click Adopt.

802.11ac Dual-Radio Long Range Access Point

For information on configuring and using the UniFi Controller software, refer to the User Guide located on our website: ui.com/download/unifi

Uap 158 - The Challenge Mac Os 11

UAP-AC-M-PRO

Dimensions

343.2 x 181.2 x 60.2 mm

(13.51 x 7.13 x 2.37')

Weight

633 g (1.40 lb)

Networking Interface

(2) 10/100/1000 Ethernet Ports

Buttons

Reset

Power Method

802.3af PoE

Power Supply

48V, 0.5A PoE Gigabit Adapter (Included)

Mastering sublime text pdf download. Supported Voltage Range

44VDC to 57VDC

Max. Power Consumption

9W

Operating Frequency

2.4 GHz

5 GHz

Max. TX Power

  • 2.4 GHz
  • 5 GHz
  • 22 dBm
  • 22 dBm

MIMO

  • 2.4 GHz
  • 5 GHz
  • 3 x 3
  • 3 x 3

Antennas

(3) Dual-Band Internal

Antenna Gain

8 dBi

Wi-Fi Standards

802.11 a/b/g/n/ac

Wireless Security

WEP, WPA-PSK, WPA
Enterprise (WPA/WPA2, TKIP/AES)

BSSID Best video slots play.

Up to Four per Radio

Mounting

Wall/Pole (Pole Kit Included)

Operating Temperature

-40 to 70° C (-40 to 158° F)

Operating Humidity

5 - 95% Noncondensing

Certifications

CE, FCC, IC
